S.No | Parts check list | Qty |
01. | Head Board | 1 |
Fittings check list | ||
02. | Screw BMK x A2 – 70 | 7 |
03. | Screw | 28 |
04. | Allen Key | 1 |
05. | White ribbed plastic anchor for screw | 8 |
06. | Attachment clip | 3 |
07. | T lock screw with white plastic anchor | 2 |
08. | Cleat | 1 |
1. Unpack the head board (01). |
2. Install the cleat (01) with the help of screws (03) and ribbed white plastic anchor(05) at your desired height. Similarly install the T lock screw (07) on the wall with the help of ribbed white plastic anchor provided with the kit. |
3. At this stage and after you require two people. Hold the head board from both sides and mount your headboard by lifting its cleat plate up and over the installed cleat so it fits between that and the wall. |
4. Similarly adjust the T Lock screw and fix it in the T lock provided at the bottom of the head board and finally the head board is fixed to the wall. |
5. Illustration demonstrating the correct placement of the three attachment clips (06) included in the kit for securing the bed frame structure to the headboard. |
